Nivotemp NT 61D, Nivovent NV 71D
Temperature outputs
Choose from the following temperature outputs
-2T -1T-KT -4T
Plug (base) 2 x M12 – 4-pin 2 x M12 – 4-pin 1 x M12 – 4-pin
1 x M12 – 8-pin
Switching outputs
2 x freely programmable* 1 x freely programmable* 4 x freely programmable
Alarm memory with 1 x assignable to alarm
logbook
with 1 x assignable to alarm
logbook
max. switching current** 0.5 A per output
continuous short-circuit
protected
0.5 A per output
continuous short-circuit
protected
0.5 A per output
continuous short-circuit
protected
Contact load max. 1 A total max. 1 A total max. 1 A total
Analogue output Analogue output
Max. burden Ω
as current output
=(U
B
-8 V) / 0.02 A
Min. input load
as voltage output
10 kΩ
*also programmable as frequency output
**Output 1 max. 0.2 A.
