Bunn CDBCF TC-DV - Page 25

ITEM PART NO. QTY. QTY. DESCRIPTION
TWIN SINGLE
25
* Indicates the part number listed is OBSOLETE. ^ Indicates the part number listed is for reference only.
FILL SOLENOID VALVE AND DRAIN
1 38969.0001 2 1 Fitting, 90° Silicone
2 32591.0012^ 2 - Tube .5" x 8.25" (Order item 18) (TWIN)
32591.0013^ - 1 Tube .5" x 7" (Order item 18) (Single)
3 00459.0000 1 1 Fitting, Bulkhead 1⁄4" Flair
01532.0000 1 1 Lockwasher, Int. Tooth .438"
00463.0000 1 1 Nut, Hex .438"-20
4 29065.0000 - 1 Tube, Bulkhead to Solenoid (Single)
29486.0000 1 - Tube, Bulkhead to Solenoid (TWIN)
5 28750.0000 2 1 Solenoid Assy (120v)
28750.0001 2 1 Solenoid Assy (230v)
28750.0002 2 1 Solenoid Assy (100v)
28750.0003 2 1 Solenoid Assy (200v)
02325.0001 4 2 Screw .25"-20 x .313"
39975.0000 - - Solenoid Repair Kit (Includes Guide, Spring, Armature & Diaphragm)
39975.0001 - - Guide
39975.0002 - - Spring
39975.0003 - - Armature (Plunger)
39975.0004 - - Diaphragm
6 12422.0001 10 5 Clamp, SNP - 10
7 20976.0010^ 2 1 Tube, Tee To Valve, .375"ID x 3.375" (Order item 17)
8 20976.0042^ 2 1 Tube, Tee To Tank, .375"ID x 4" (Order item 17)
9 38948.0001 2 1 Tee, Plastic .375" x .375" x .375"
10 28526.0009^ 2 1 Tube, Drain, .313" x 24" (Order Item 16)
11 11630.0001 2 1 Clamp, Shut Off
12 32098.0000 2 1 Plug
13 12422.0006 2 1 Clamp, SNP - 8
14 20976.0005^ 2 1 Tube, Tank To Valve, .375"ID x 7.5" (Models with w/o Drain) (Order # 17)
The Following Items Are Not Illustrated
15 35116.0000 2 1 Kit, Tank Drain (Includes items 7 - 14)
16 28526.1001 - - Tube, .313" x 36" (Use as required)
28526.1002 - - Tube, .313" x 60" (Use as required)
28526.1003 - - Tube, .313" x 120" (Use as required)
17 20976.1000 - - Tube .375" ID x 12" (Use as required)
20976.1001 - - Tube .375" ID x 36" (Use as required)
20976.1002 - - Tube .375" ID x 120" (Use as required)
18 32591.1001 - - Tube .5" ID x 12" (Use as required)
32591.1002 - - Tube .5" ID x 36" (Use as required)
Repair Kit
