Bunn CDBCF TC-DV - Page 31

ITEM PART NO. QTY. QTY. DESCRIPTION
TWIN SINGLE
31
* Indicates the part number listed is OBSOLETE. ^ Indicates the part number listed is for reference only.
21 28975.1000 2 1 PC Board Kit, 100V-120V (APS & 0-5 Warmer Models)
28975.1001 - 1 PC Board Kit, 100V-120V (CDBCFP w/40 Minute Flashing LED)
28975.1002 - 1 PC Board Kit, 100V-120V (w/15 Minute Shut Off)
28975.1004 2 1 PC Board Kit, 200V-240V (APS & 0-5 Warmer Models)
38956.1000 2 1 PC Board Kit, 200V-240V (APS & 0-5 Warmer Models) RoHS Compliant
02362.0000 4 2 Screw, PNH #4-40 x 1.25"
38044.0000 8 4 Screw, PNH Plastite #6 x .375"
01518.0000 8 4 Washer, Nylon #6
22 34813.0000 2 1 Probe Clip Assembly (NOT FOR USE ON CEZ)
23 29673.0000 - 1 Bracket, Term. Block Mounting
24 28177.0000 - 1 Terminal Block
01317.0000 - 2 Screw #8-32 x .5"
25 29007.0000 1 1 Decal, HOT WATER (Models w/faucet)
29265.0000 1 1 Decal, Faucet Hole Cover (Models w/o faucet)
26 29006.0001 2 1 Membrane Switch (3 Left Warmers)
29006.0002 2 1 Membrane Switch (3 Right Warmers)
29006.0003 2 1 Membrane Switch (1 LWR/2 UPR)
29006.0004 - 1 Membrane Switch (1 LWR Only)
29006.0005 2 1 Membrane Switch (1 LWR/1 UPR)
29006.0012 - 1 Membrane Switch (1 LWR/2 UPR) CE
29006.0013 - 1 Membrane Switch (3 Right Warmers) CE
29006.0014 - 1 Membrane Switch APS (No Warmers) CE
29006.0018 2 1 Membrane Switch APS (No Warmers)
27 12921.0000 2 1 Switch Blank, Black
28 01063.0000 2 1 Switch, Momentary Start
29 12920.0000 6 3 Switch, On/Off
30 12517.0001 2 1 Green LED Kit (Includes Wire Nuts)
31 03851.0000 4 2 Wire Nut, 2-22 AWG
32 23376.0000 1 - Bracket, Term. Block Mounting
02308.0000 3 - Screw, Pan Head #8-32 x .375"
33 29484.0000 1 - Wiring Harness, Terminal Block (Models w/one Power Cord Only)
29484.0001 1 - Wiring Harness, Terminal Block (Models w/one Power Cord & Switch)
34 38894.0001 1 1 Switch, On/Off (Models w/o 120V Power Cord)
01308.0002 2 2 Screw, TRH #6-32 x .25"
35 02812.0001 - 1 Wiring Harness, (P1,2,3) to Top Warmers CDBC/CEZ
24204.0000 1 1 Wiring Harness, (P1,2,3) to Left Side Warmers CDBC-35 & 0/6 4/2 TWIN
24204.0001 1 1 Wiring Harness, (P1,2,3) to Right Side Warmers CDBC-15/35 & 0/6 4/2
25348.0002 2 1 Wiring Harn, Top Warmers CDBC-35 (1 Top Warmer) & 2/2 TWIN
The Following Items Are Not Illustrated
36 20555.0011 2 1 Red LED Kit, CDBCFP w/FL. LED
37 21016.0011 - 1 Lead, Grn/Yel, 15" LG (CE) CDBCF-35 & CDBCFA
21016.0027 - 2 Lead, Grn/Yel, 26" LG (CE) CDBCF-35 & CDBCFA
38 28743.0000 2 1 Wiring Harness, Level Probe to Board CDBC
Included in PC Board Kits
MV Models Only
Continued on next page
ELECTRICAL AND OPERATING CONTROLS
