6
08/54071/0 (ISSUE 2)
Technical Data
Installing Burco boiler
Mounting to wall
Please ensure there is at least 220mm of clearance below the boiler to allow for filter changes, the location
must be frost free.
The unit must be installed on a solid concrete / brick or other suitably robust wall, with
appropriate fittings by a qualified fitter. The company does not accept any responsibility for the safety
of any unit not installed in this way.
1. Mark the position of the 2 mounting holes 300mm apart as shown in the diagram below.
2. Ensure the marked positionas are level.
3. Drill the wall and insert suitable wall plugs and screws.
4. Fix the wall bracket, from the accessory kit, to boiler. 4.5mm hole screws to boiler, this screw is included
and can be found in the base of the boiler.
5. Hang the boiler on the two top lugs and locate the third hole position.
6. Drill the wall and insert suitable a wall plug.
7. Fix the boiler to the wall using a suitable screw.
