8
08/54071/0 (ISSUE 2)
Electrical Connection
Electrical Safety
All electrical work must comply with all relevant wiring regulations and carried out by a qualified
electrician.
To protect against fire, electric shock and personal injury, do not immerse cord, plug, or water boiler in
water or any other liquid.
If the supply cord is damaged, it should be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid hazard.
This appliance must be earthed.
The wires in the mains lead are coloured in accordance with the following code:
Green & Yellow Wires Earth E
Blue Wire Neutral N
Brown Wire Live L
Means of isolation with at least 3mm contact separation in all poles must be incorporated into fixing of this
appliance.
The fixed wiring insulation must be protected by insulated sleeving having a temperature of at least 60˚C.
Supply cords should be oil resistant, sheathed flexible cable not lighter than ordinary polychloroprene or
equivalent elastomer sheathed cord (code 60227 IEC 57).
The appliance is supplied with a terminal block suitable for flexible wires up to 6mm².
Overflow and Drainage
As an option, the boiler overflow outlet may be connected to a drainage system.
There may be some steam emitted from the vent at the base of the appliance during the initial fill stages
(or if the tank is refilled after being fully emptied) but this will reduce as the volume of water increases in the
tank. As an alternative, a flexible hose may be used redirected steam to a sink/draining board.
The flexible hose connected from the over flow also acts as a vent for the appliance. Under no
circumstances should this flexible hose become blocked or restricted in any way.
