Burley DASH RM - Adjusting Harness Position

OWNER’S INSTRUCTION & SAFETY MANUAL
13BURLEY.COM
ENG
Adjusting the Harness Position
The upper shoulder strap attachment points have two positions that can be adjusted according to
the child’s size.
1. Access the Rear Bracket on the back of the Bicycle Seat [Figure 13].
2. Rotate the Rear Bracket sideways, and slide it through the lower harness adjustment hole and
the slot in the seat pad [Figure 14].
3. Pass the Rear Bracket through the upper harness adjustment hole, then rotate it so that it is
secure against the rear seat back [Figure 15].
4. Repeat steps 1-3 for the other shoulder strap. Ensure that harness straps are not twisted during
harness adjustment [Figure 16].
NOTE: If you are adjusting from the upper harness position to the lower harness position, the
Rear Bracket will need to be passed back through the slot in the seat pad before passing it
through the lower harness adjustment hole.
Figure 13
Figure 14
Figure 15 Figure 16
