Burley DASH RM - Removing Bicycle Seat From Bicycle

CHILD BIKE SEAT
ENG
14
Removing the Bicycle Seat From Your Bicycle
1. Detach the Safety Strap by releasing the buckle.
2. Pull the Locking Ring towards the Adjustment Knob [Figure 17a] and rotate the Adjustment
Knob counter-clockwise [Figure 17b] until the Rack Clamp is wider than the width of the bicycle
rack [Figure 18].
3. Lift the Bicycle Seat up off the bicycle rack to remove it from the bicycle [Figure 19].
Figure 17 Figure 18
Figure 19
A
B
