5
MANUAL CONTROL
1.8 There are 2 control knobs on the appliance. The right hand one controls On/Off and
pilot/main burner. The left hand one is the comfort level thermostat which turns the fire
down once the indicated temperature is reached. If during use the pilot is alight but the
main burner is not lit, check the thermostat position and if necessary select a warmer
setting. The range of the thermostat is around 13
o
C – 45
o
C.
Thermostat knob Ignition knob
1.9 To light the fire, first ensure the right hand control (Ignition) knob is turned clockwise to OFF,
and then press the knob for several seconds then turn slowly anticlockwise to the ignition
position. A click will be heard and the pilot (under right side of fuel bed) should light. If it does
not, repeat the operation a few times to purge any air in the pipe. Continue to hold knob for
15 – 20 seconds to establish the pilot and then release. If the pilot fails to establish, turn off,
wait 1 minute then repeat lighting procedure. Once the pilot has been established rotate the
knob counter clockwise towards the larger flame symbol to light the main burner. If no gas
comes through to the main burner, rotate the left hand knob (thermostat) to a hotter room
setting and the fire will light. Pilot burner position
Main burner position
Main burner operational & thermostatically controlled
1.10 To turn the fire off, rotate the right-hand knob fully clockwise back to its OFF position.
