OPERATION MANUAL 077 PREAMPLIFIER
Furthermore you have the option to switch through all inputs, independent of the
names, with the buttons STATION+ and STATION-. With the STATION+ button in
ascending order (INPUT 1  INPUT 2  etc…), with the STATION - button in
descending order (INPUT 4  INPUT 3  etc…).
PLEASE NOTE: To be able to use the STATION keys you have to activate
the option in the GLOBAL SETUP / RC INPUT.
PLAYBACK VOLUME
With the buttons VOLUME + and VOLUME - you are able to adjust the volume
for the selected MAIN or RECORD level. The volume level is shown in the display.
By shortly pressing the VOLUME buttons you are able to change the volume in
small steps.
To be able to use the volume buttons on the RECORD level you have to choose
the function VARIABLE VOLUME in the RECORD MENU.
DISPLAY BRIGHTNESS
With the DIM button you are able to adjust the brightness of the display in 4 steps.
These steps vary between “max. brightness” and “off”.
If you choose the option “off” the display will only light up when you change
anything. This gives you a feedback about the changes you are applying.
When you are done with your changes, the display will go blank again after a couple
of seconds. If you enter the SETUP MENU while display is “off”, it will automatically
go to “maximum brightness” for the time you are in the SETUP MENU.
MAINREC CHANGE
Shortly pressing the MODE button will allow you to switch between MAIN and
RECORD level.
PHASE REVERSAL
Longer Pressing the DIM button (approx. 2 seconds) will reverse the phase of
the presently activated input channel by 180°. When the phase reversal is active,
the PHASE LED (2) will light up.
UP SAMPLING
If you have a D/A-converter module, and the module input is selected you are able
to change the sample rate between 192kHz (SRC LED (3) lights up) and 96 kHz
(SRC LED (3) is off). You may do so by shortly pressing the AUDIO button.
Remote Control
Equipped as standard is the 005 remote control
SWITCHING ONOFF
The POWER button switches the preamp on or off, provided the Mains switch of the
external power supply unit or on the rear panel of the preamp is set to ON and the
power switch on the front panel of the preamp is set to STBY.
INPUT SELECTION
The buttons TUNER, PHONO, TAPE, DISC, AUX, SURR activate the according
input. If you have renamed the inputs the buttons will react as follows:
TUNER:
all inputs with the character combinations TU, DAB, DVB, ADR, RADIO, RDS, 053,
993, 931, 915, 978 in its name
PHONO:
all inputs with the character combinations PH, VINYL, PLATTE, in its name
TAPE:
all inputs with the character combinations TAPE, DAT, REV, BAND in its name
DISC:
all inputs with the character combinations CD, DVD, DISC, BD, MD, LD, VD, 001,
006, 052, 061, 069, 088, 992, 937, 916, 917, 963, 939 in its name
AUX:
all inputs with character combinations which are not listed above will be toggled
through
SURR:
the INPUT 6/SURR can only be operated if you select SURROND in the SETUP
menu for INPUT 6
NOTICE: If you have multiple inputs with same characters (for example CD1
and CD2), you will be able to toggle through those inputs with the DISC
button on your remote control.
