Installation / Service / User Manual BURNERTECH

4.2 Burner Mounting

To mount the burner, suitable mounting studs or threads for bolts need to be provided for the burner

Mounting Plate. Appropriate dimensions are shown below. When installing the burner, please be

sure to use the gasket provided for sealing and insulating between the Mounting Plate and the

bearing wall of the appliance.

4.2.1 Standard Burner Mounting Detail

Model F G R 2R

mm deg. mm mm

Inverterjet 50/M 138 45  4.5 9

Inverterjet 90/M 138 45  4.5 9
