Bush Hog LOADER 3045 - Page 55

BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
1-20F-5
24H41918 POWER BEYOND KIT
For Walvoil Valve
Used on Model 3045 Loader
REF. PART
NO. NO.
QTY. DESCRIPTION
1 52161 2 Cable Tie
2 53338 1 90° Elbow, 9/16” ORB to 9/16” JIC
3 53329 1 Hydraulic Hose 9/16” – 18 JIC
4 25H42225 1 Quick Coupler
5 25H43318 2 Straight Fitting, 9/16” JIC Male to 3/8” Pipe Male
2
3
5
5
4
1
Note: Power Beyond plug is shipped
in the Control Valve package.
HOSE BUNDLES
For Walvoil Valve
Used On: 3045
2
3
1
6
5
REF. PART
NO. NO.
QTY. DESCRIPTION
1 50029353 1 Long Hose Bundle
2 50029351 1 Hose Assembly 70” x 9/16” - 18 JIIC Female to 3/4” - 16 JIC Female
3 25H43753 1 Hose Assembly 70” x 9/16” - 18 JIC Female Both Ends
4 50029352 1 Short Hose Bundle
5 6050122 1 Hose Assembly 48” x 9/16” - 18 JIC Female Both Ends
6 50006622 1 Hose Assembly 47” x 9/16” - 18 JIIC Female to 3/4” - 16 JIC Female
4
JULY, 2007
