1-20H-8
BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
50049205 HYDRAULIC ADAPTOR KIT
Used on Model 3045 Loader
with Massey Ferguson 451 Tractor
1
2
Note: This Adapter is shipped with the Control Valve package.
(See valve mount instructions for proper assembly)
4 (Optional)
3
5
6
7
REF. PART
NO. NO.
QTY. DESCRIPTION
1 50043879 1 Hydraulic Swivel Reducer
2 50043880 1 Hydraulic Adapter
3 50049203 1 Hydraulic Adapter
4 25H40576 1 Standard Tread Elbow 90°(Optional)
5 25H42696 1 Hydraulic Adapter
6 25H50711 1 Hydraulic Hose 102”
7 25H49697 1 Hydraulic Hose 93”
POWER BEYOND SLEEVE
AGCO Part Number #6207263M91
( Purchased by Dealer - see Note 3 )
SEPTEMBER, 2006
