Installation
C
ustomer Helpline 0345 257 7271
Changing the oven injector
Open the oven door.1.
Locate the retaining screw below the burner2.
as shown in fi gure 8.
Remove the screw and withdraw the burner3.
diagonally to reveal the injector as shown in
fi gure 9.
Using a 7mm spanner, unscrew the injector.4.
Select an appropriate injector for the5.
desired gas using the information chart
supplied with the gas conversion kit.
Fit the replacement injector to the6.
appliance.
Refi t the burner and screw.7.
Figure 8
Figure 9
Clip
Injector
