Installation
C
ustomer Helpline 0345 257 7271
Gas conversions
WARNING - Gas conversions must only be carried
out by suitably qualifi ed personnel.
The appliance can be converted to operate on LPG
by replacing the appliance’s injectors and adjusting
the minimum fl ame length.
Replacement injectors are supplied as part of the
gas conversion kit.
Changing the hob burner injectors
IMPORTANT - The following procedure must be
performed on each hob burner.
Disconnect the Gas supply and mains1.
electricity supply from the appliance.
Remove the hob cap and adapter.2.
Using a 7mm spanner, unscrew the injector3.
as shown in fi gure 5.
Select an appropriate injector for the4.
desired gas using the information chart
supplied with the gas conversion kit.
Fit the replacement injector to the appliance5.
and tighten using a 7mm spanner.
Refi t the hob cap and adapter.6.
Changing the grill injector
Open the oven door and locate the retaining1.
screw on the tip of the grill burner as shown
in fi gure 6.
Remove the screw and withdraw the burner2.
to reveal the injector as shown in fi gure 7.
Using a 7mm spanner, unscrew the injector.3.
Select an appropriate injector for the4.
desired gas using the information chart
supplied with the gas conversion kit.
Fit the replacement injector to the5.
appliance.
Refi t the burner and screw.6.
Figure 5
Figure 6
Figure 7
Spanner
Screw
Injector
7
