Bush BHAS01UR - HDMI Connection (High Definition)

14
BHAS01UR
Connect the STB receiver via HDMI
(for optimum high denition viewing)
Connect the antenna to the ANT IN socket on the receiver.1
Connect the receiver to the TV set via a HDMI cable. This will provide both video 2
and audio.
TO TV
RF N
RF OUT
R L CVBS
Pr
Pb
Y
S/PDIF
HDMI
USB
ON OFF
SK F L C R S OCK
O N T P N
CAUTION
L R Video Pr Pb Y
HDMI
RF IN
TV CONNECTION PANEL
TERRESTRIAL
ANTENNA
SET TOP BOX REAR PANEL
