Plug replacement - UK and Ireland only
Connect green/yellow
lead to ‘E’ or - Earth
Connect
blue lead
to ‘N’ -
Neutral
Connect
brown lead
to ‘L’ - Live
N
L
E
Should you need to replace the plug; the wires
in the power cable are coloured in the following
way:
Blue – Neutral ‘N’
Brown – Live ‘L’
Green & Yellow – Earth ‘E’
As the colours of the wires in the power cable
may not correspond with the coloured markings
identifying the terminals in your plug, and proceed
as follows:
The green & yellow wire must be connected to the
terminal in the plug that is marked with the letter E
or by the earth symbol.
The blue wire must be connected to the terminal
that is marked with the letter N.
The brown wire must be connected to the terminal
that is marked with the letter L.
If the power lead is damaged, it must be replaced
by a qualifi ed electrician.
5A Fuse
34
