Hose connection
Warning:
install the hose. It is recommended to
wear the gloves
2 people may be required to
NOTE:
air from the inside of the tumble dryer.
Ventilation hose assures exhausting of the
Carefully remove all packing materials including
from the foam, dispose of correctly.
Before installation, ensure that the unit is power off
and unplug from the mains.
1.Connect hose to the air outlet of the machine by
screwing it tight in a clockwise direction.
2.Extended the hose to the suitable length.
3.Route the hose to the outdoors via a window or
it can be connected to an outlet in the wall (see the
diagrams).
The air outlet hose must be extended directly to
the outdoors. Keep bends to a minimum to ensure
adequate ventilation.
To prevent water accumulation in the hose, make
sure the hose is not folded on the floor.
In winter, the room temperature may be cold. The
water may condense inside the hose. Periodical
check is required to avoid hose damaged by the
water.
Warning: Do not connect the hose to the
chimney of a stove or fireplace.
Fig5
Fig6
Fig7
Levelling feet
1:For your machine to work efficiently with
minimum vibration it should be settled on flat,
nonslippery,firm ground.
2:You can adjust the balance of your machine by
changing the positioning of its feet.
3:First,loosen the plastic adjustment nut.(Fig 3)
4:Adjust by rotating the feet upwards or
downwards.(Fig 4)
5:After the desired position has been reached,
tighten the plastic adjustment nut again by rotating
it upwards.
Note:Never put cartons,wooden blocks or similar
materials under the machine to balance
irregularities in the level of the ground.
Fig3
Fig4
