USE TOP HOLE FOR 1501310
FRONT AND REAR CROSSBARS
USE BOTTOM HOLE WHEN 1501311
IS USED AS A CENTER CROSSBAR
ALTERNATE CLAMP BRACKET (3023087)
M12 CAPSCREW
WITH LOCK WASHER and
FLAT WASHER
M10 CAPSCREW
M8 CAPSCREWS
WITH FLAT WASHERS
AND LOCKNUTS
DIVIDER BRACKET
SIDE MOUNT TUBE
GUTTER MOUNT BRACKET
CLAMP BRACKET (3022873)
Fig. 1
Fig. 2
