2020/10 - Indice de révision : D - Code : 25110 CONSTRUCTION & RÉNOVATION
12/32
1. RECOMMANDATIONS
1.1 Purpose of the product
• To allow the water level in the pool to be raised to 50 mm from the top of the pool wall.
• Skims the surface of the water.
• Captures large debris (leaves, toys, large insects, etc.)
• Overow, to be punched out
• Leaktight installation with a liner (75/100, 85/100, 150/100)
1.2 Tools and number of people required for installation
• Same as a standard skimmer. According to the DTP n°8 «pool tting» (January 1998)
• Use only the brous concrete and welded mesh provided to seal in the copings beside the mirror skimmer
• You will need 2 pieces of Hung liner locking track to be placed under the ends of the SS reinforcement.
1.3 Limitations of use
Pool coping
• Min length 500 mm
• Min depth 30 mm
1.4 Safety advice and recommendations
• The mirror skimmer must be installed with an automatic water level regulator and an overow system.
• The “Hung“ liner locking track must be placed on 2 silicon beads.
• Linerlock must be used to ensure a leaktight seal.
1.5 Upkeep and maintenance
As for pool ttings.
2. ASSEMBLY INSTRUCTIONS
2.1 Sealing in the skimmer
• Position the mouth ush with the wall
• The SS reinforcement is placed on 2 pieces of Hung (just behind the hook section).
