• Skimmer mouth
Clean the entire underside of the skimmer mouth using a rag soaked in a PVC compatible solvant, then
sand it using a rough grain emery paper to improve the adhesion of the brous concrete to the ABS surface.
• Place the support column in the centre of the skimmer mouth
• Position the welded mesh, making sure that the ends coincides with the pool chaining
2.2 Fitting the Hung liner track
• Once the peripheral chaining is dry, remove the 2 Hung blocks.
• Smooth out any roughness around the Hung liner locking track around the entire periphery of the pool.
• Remove any dust and lay down 2 silicon beads before mounting the Hung liner locking track
This is essential for ensuring leaktightness between the Hung track and the top of the pool wall.
2 silicon beads
