BYD DESS-B08P03A-A - Page 8

Distributed Energy Storage System Build Your Dreams
6
Fig 3.2 Rotary switch on left side of the cabinet
Fig 3.3 Circuit breakers on left side of the cabinet
GRID
DISCONNECT
AC-BIG-SI
DISCONNECT
AC-OUTPUT
DISCONNECT
AC-SI
BYPASS
AC-OUTPUT
BYPASS
AC-SI
DISCONNECT
AC-INPUT
DISCONNECT
Bypass rotary
switch
Circuit breakers
NORMAL
BYPASS
