Name plate light
1. Pull off the Name plate light
connector while pressing down the
buckle as shown in figure.
If the connector is too tight, shake it
first.
2. Rotate the light seat anticlockwise
and pull it outwards to remove the
light seat.
3.Pull off the bulb from light seat,
replace the bulb.
Trunk light
1.Move the claw as shown in figure.
2.Pull off the bulb from light seat,
replace the bulb.
