ʒ Mirror Surface ʓ LED Strip Light
ʔ Touch Switch ʕ Display Screen˄Visible when double-click˅
ʖ Defogging˄Visible when single click˅ ʗ Mounting Brackets
ʘ Temperature Humidity Sensor
INSTALLATION
˄1˅Choose the mounting position, keep the required minimum distances˗
˄2˅Mark the positions for the bore holes onto the drilling template (D) if there are no
existing marks. Stick the drilling template on the wall˗
˄3˅Drill the holes. Insert the screws into the dowels and fasten the screws. The screws
should protrude approx.1.5 cm from the dowels˗
˄4˅Tear off the back protective film,
Hang the mirror (A) on the screws and move it to
one direction.
Note: please tear off the front and back protective film once you start to use.
