ADJUSTMENT
PROCEDURES
continued)
e
Tracking
gain
adjustment
1.
Adjustment
is
made
in
the
same
manner
as
for
focus
gain.
The
input
from
the
frequency
generator
is
set
to
1,200Hz,
HF
0.5Vp-p,
and
P104
is
adjusted
so
that
the
phase
difference
@
1V/DIV
,)
is
90°.
50uSec/DIV
TE
0.5V/DIV
;
50nSec/DIV.
Waveform
showing
Short
Kick
Gain
HF
1V/DIV
50uSec/DIV,
ADJUSTMENT
OF
KICK
GAIN
1.
Load
the
test
disc
YEDS4
on
the
turntable.
2.
Set
the
oscilloscope
at
the
NORMAL
TRIG.
and
connect
the
TE
TRHD
(TP6)
of
connector
CN8
to
the
external
trigger
0.5V/DIV
terminal.
Then,
connect
the
channels,
1
and
2,
to
the
test
Cae
pin,
HF
(TP1)
and
TE
(TP4),
respectively.
3.
Switch
on
the
power.
In
the
state
of
playing
the
first
tune,
make
it
pause
and
observe
the
waveforms
of
HF
and
TE
Waveform
showing
Excessive
Kick
Gain
triggered
by
TRHD.
4.
Adjust
the
P106
for
making
a
track
jump
between
1
and
1.5
track.
HF
1V/DIV
50“Sec/DIV
TE
a
0.5V/DIV
504.Sec/DIV.
