11
Rear Panel Functions
Made in China
❷❸ ❹❶
SPEAKERXLR INPUTRCA INPUT
RIGHT LEFT
RIGHT LEFT
CEC株式会社
CEC Co., Ltd., Japan
Headphone Amplifier
Model: HD53N
Connect the interconnect cable
in the correct direction
aligned for the signal path
❶
RCA Input
Line in audio signal input jacks equipped with unbalanced RCA connectors.
Use interconnect RCA cables to connect the RCA input to external sources
with RCA line output, such as CD player, tuner or tape deck.
*Phono and digital sources cannot be connected to the RCA input.
❷
XLR Input
Line in audio signal input jacks equipped with balanced XLR connectors. Use
interconnect XLR cables to connect the XLR input to external sources with
XLR line output, such as CD player, DVD player or DA converter. Due to a
full balanced circuitry design the balanced XLR connection is recommended
To Next Page
