CM2 Sidescan Sonar User Manual 14. Interfaces
C-Case SE Interface
Tow cable or winch deck cable
MIL-C-5015, size 14, threaded, 4-way bulkhead connector
Sockets A and B; polarity not significant
Power input input (see C-Case SE Specifications for power requirements)
MIL-C-5015, size 14, threaded, 6-way bulkhead connector
Pin A = - ve DC, pin B = +ve DC, pin C = N/C, pin D = AC (L), pin E = AC (N), pin F = chassis Gnd
Navigation data port (RS232 serial port)
MIL-C-5015, size 14, threaded, 4-way bulkhead connector
Pin A = gnd (= D-type skt 5), pin B = RX (= D-type skt 2), pin C = TX (= D-type skt 3), pin D = N/C
Counting pulley port (RS232 serial port)
MIL-C-5015, size 14, threaded, 6-way bulkhead connector
Skt A = gnd (= D-type skt 5), skt B = RX (= D-type skt 2), skt C = TX (= D-type skt 3),
Skt D = DTR (= D-type skt 4), skt F = RTS (= D-type skt 7)
PC link (internal)
MIL-C-5015, size 14, threaded, 4-way bulkhead connector
Pin A = gnd, pin B = 5V, pin C = data-, pin D = data+ ; USB1.1 or 2.0
PC power, 15.6VDC (internal)
MIL-C-5015, size 10, threaded, 2-way bulkhead connector
Skt A = gnd, skt B = 15.6VDC
Winch and Counting Pulley Interfaces
Consult Sections 16, 17 or 19 for interface information on these optional accessories.
Version 3.6 (2008)
29
