C-Media HS-100B - Take a Close Look at HS-100 B Demo Board

HS-100B
USB Audio Demo Board User Manual V1.0
Worldwide Solution That Touch People’s Hearts! - 6 -
1.2 Evaluation Board Contents
The HS-100B controller demonstration board has several hardware features. With each
feature’s description in Figure 1, the feature’s location can be clearly identified.
Figure 1
LED Indicators
Microphone in
Headphone
USB Jack
EEPROM
HID Function Keys
HS-100B
