Instruction Booklet6-Series
6
Thumb Levers :
Pushing right thumb lever moves scooter forward. Pushing the left thumb lever moves
scooter backward. Releasing both engages automatic brake.
Seat Adjustment :
Seat Control Slide :
lift up lever under front edge of seat base to move forward and backward.
Seat Rotation Lever : push lever back to rotate seat; push forward to lock seat in position.
Tiller Angle Adjustment Lever :
Push lever down to adjust, release to lock Tiller Angle Adjustment in comfortable angle.
High/Lo Speed Switch :
When High/Lo Speed Switch is in High position, scooter performs in normal. If it is in the
Lo position, the scooter travels in half of normal speed which is convenient for side-walk
use.
Rear Cover :
Protects batteries from damage.
Anti-tip device :
Helps keep the scooter from tipping over.
Free-Wheeling Lever :
When lever is in N (Neutral) position, scooter can be moved without power.
When lever is in D (Drive) position, scooter can be driven. Normal position is D.
Function of parts：
Self Diagnostic Warning Light:
Flashing indicates problems within scooter. See page 14 for more information.
Battery Gauge Indicator:
This light is yellow
. Below it are three color ranges: red, yellow and green. When all lights
are on batteries are fully charged. When light is on, only in red, or red and yellow areas,
the batteries need to be recharged.
Batteries:
Two 12 volt sealed batteries.
Battery charger:
The battery charger is a 24 volt, 5 amp, constant current charger.
Accessories:
These can be ordered from your local distributor.
•Additional Mirror •Rear basket
•Storage cover •Cane holder
View of the Control Panel at top of steering column：
