english
Power supply
The
AC in
-
cord must be connected to the mains to supply
the subwoofer. The selection of the right voltage 115V - 230 V
is done with 115V- 230 V
=
. Switch
POWER
q
, on
STAND BY
or
ON
. With the switch on the
STAND BY
position, the unit will
mute after a few minutes without input signal. The system
turns on automatically when signal comes back.
Adjustments
■ LEVEL
w
For a first volume adjustment, position the
CROSSOVER
FREQUENCY
e
at around 120 Hz, and turn slowly the
LEVEL
w
clockwise from minimum level up to a position where you feel that
the subwoofer sound level is appropriate. A check of the level
adjustment will be necessary after following steps.
■ CROSSOVER FREQUENCY
e
This potentiometer adjusts the cut-off frequency which deter-
mines the working bandwidth of the subwoofer. This adjust-
ment should be done according to the specifications of the
main speakers and the room acoustics. Choose the best fre-
quency after various listening tests.
■ PHASE
r
For a better sound integration of the subwoofer in the main
system, the
PHASE
r
of the subwoofer might have to be
inverted (180° position), depending on the distance between
the subwoofer and the main speakers. You have to check the
PHASE
r
each time you move your speakers and each time
you adjust the
CROSSOVER FREQUENCY
re
.
Attention, if you use 2 subwoofers, both phase switches must
be on the same position.
Our web site
www.cabasse.com
will give you the specific adjust-
ments we recommend for the use of our active subwoofers.
MAINTENANCE
The MC40 cabinets are made of medium density fiber panels,
protected by synthetically veneer with two coats of varnish
and a special anti-scratch film. This hi-tech veneer does not
require any specific care. Use a wet cotton waste for cleaning,
or any cleaning device for wood or plastic.
ACTIVE SUBWOOFER MERCURE MC40
Pulsed sound pressure 114 dB
Phase switch 0° normal
180° reverse
In put 2 low level - 2 hight level
Voltage 115 / 230 V AC-50/ 60 Hz
Maximum power consumption 165 W
Because of technical improvements already under way in our constant search for optimum quality,
Cabasse
reserves the right to modify all the models presented in specification sheets, advertising materials and manuals without prior notice.
Sensivity
Cross-over
Frequency Nominal Minimum Power Peak Standard Dimensions Weight
1W/1m points response impedance impedance handling power finish hxlxp (cm) (kg)
(dB) (Hz) (Hz) (ohms) (ohms) (Watt) (Watt) h x l x p (”) (lbs)
10 89 900- 69-23 000 8 3.3 75 550
cherry with anthracite + beige front grills
40 x 23 x 28 8,5
3 200 purple cherry with anthracite +
15”
3/4
x 9” x 11”
19 lbs
beige front grills
10 90 900- 59-23 000 8 3.4 110 770
cherry with anthracite + beige front grills
110 x 25 x 35 24,5
3 400 purple cherry with anthracite +
43”
1/3
x 9”
5/6
54 lbs
beige front grills
x 13”
3/4
10 90.5 800- 49-23 000 8 3.2 150 1,000
cherry with anthracite + beige front grills
115 x 29 x 35 27,5
3 200 purple cherry with anthracite +
45”
1/4
x 11”
5/12
60 lbs
beige front grills
13”
3/4
10 89.5 900- 70-23 000 8 3.2 75 550
cherry with anthracite + beige front grills
18 x 49 x 35 11,5
V3200 purple cherry with anthracite +
7”
1/12
x 19”
1/4
25 lbs
beige front grills
x 13”
3/4
10 90 900- 79-23 000 8 3.3 75 550
cherry with anthracite + beige front grills
35 x 32 x 15 7
3 200 purple cherry with anthracite +
13”
3/4
x 12”
7/12
15 lbs
beige front grills
x 5”
11/12
active adjustable 35-200 active active 250 750
cherry
44 x 36 x 45 22
30-180 purple cherry
16”
11/12
x 14”
1/6
48 lbs
WEEE MARK
Disposal of Wastes of Electrical &
Electronic Equipment (Applicable in the
European Union)
This symbol on the product, consisting of the crossed-out
wheeled bin, indicates that this product shall not be treated
as household waste. Instead it shall be handed over to the
applicable collection point for the disposal of electrical and
electronic equipment at the end of life.
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inap-
propriate waste handling of this product. The recycling of
materials will help to preserve natural resources. For more
detailed information about recycling of this product, please
contact your local city office, your household waste disposal
service or the shop where you purchased the product
