When setting up the absolute power mode, the
V6 TX will collect the ash prof iles being
selected by the RX units in the same channel
and rescale them to the unif ied light
intensity scale. The following example shows
how the model-specif ic relative power scales
are translated into the absolute power
sca le.
ABSOLUTE LIGHT
INTENSITY
SCALE IN EV
R E L AT I V E L IG H T I N T E N S I T Y S C A L E
O F 4 F L A S H E S W I T H DI F F E R E N T F U L L
POWER GUIDE NUMBERS
FLASH
A
FLASH
B
FLASH
C
FLASH
D
18
17 GN58
16 1/2 GN41
15 GN29 1/4 1/2
14 1/2 1/8 GN21 1/4
13 1/4 1/16 1/2 1/8
12 1/8 1/32 1/4 1/16
11 1/16 1/64 1/8 1/32
10 1/32 1/128 1/16 1/64
9 1/64 1/32 1/128
8 1/128 1/64
7 1/128
6
