59
3. Adjust the power level of each group as
you would with the V6 RX.
To control the zoom level of the RF60 Slave:
1. Conf igure the swap control to Zoom
(Cactus) mode (see Section 15.2).
2. In the main screen of the V6 TX, press
once. The zoom levels of the activated
groups will be shown on the screen.
3. Adjust the zoom level of each group as
you would to adjust the power level (see
Section 12.1). The zoom control supports
both single group and multi-group
adjustments.
Note: The zoom level set in the V6 TX will
N O T c o n t r o l t h e z o o m l e v e l s of t h e a s h e s o n
the V6 RX.
You may also combine the RF60 with other V6-
c o m p ati b le T T L a s h e s t o f o r m a r e m o t e a s h
control system. For example, assign a RF60
to group A, a Canon 580EX II (with a V6 RX)
to group B, and a Nikon SB-900 (with another
V6 RX) to group C. The V6 TX will be able to
trigger them all and set their power levels
in either relative or absolute power mode.
