Programming
7. Enter [XXX] [✻], where [XXX] is a zone number (1
through 192) and [
✻] is the entry key.
Notes
Three beeps from the keypad indicates an entry error.
This occurs if you enter a transmitter number that is not
within the module’s zone block or if you try learning a
sensor that is already learned into the module.
If you change your mind about your entry, terminate pro-
gramming by entering [0] [#] [0] [
✻] and start over from
step 6.
8. Trip the desired transmitter (within 250 seconds) as
described in Table 4. Listen for the ‘ding dong’ for con-
firmation.
9. Program remaining transmitters by repeating steps 5-7.
10. Exit program mode by entering [EXIT] [EXIT].
Program Transmitter and Partition
Settings
This section describes programming guidelines, how to
change the supervision windows, and program the transmit-
ter and partition settings using the information you entered
in “Table 3: Module Programming Settings.”
Changing the Transmitter Supervision
Windows
Note
For UL Listed installations, the normal supervision win-
dow must be set to 24 hours and the fire supervision win-
dow must be set to 4 hours.
&$87,21
Do not set the normal or fire supervision windows to 1
hour. This causes false trouble reports from all learned
wireless transmitters.
1. Enter [✻] [8] at the keypad. The five function lights
should start flashing.
2. Enter the “Go To Program Code” (factory default is 9 7
1 3). The service light should flash and the five func-
tion lights should change from flashing to on steady.
3. Enter [XX] [#], where [XX] is the DIP switch setting
module number and [#] is the entry key. The Armed
LED should turn on, indicating the control panel is
waiting for a programming location entry.
4. Enter [195] [#] to enter location 195, segment 1.
5. Enter the new normal supervision time (0 - 255).
Note
Choosing 0 sets the normal supervision window to 256
hours.
6. Press [✻] to save any changes and automatically enter
segment 2.
7. Enter the new fire supervision time (0 - 255).
Note
Choosing 0 sets the fire supervision window to 256
hours.
8. Press [✻] to save any changes and automatically enter
segment 3.
9. Enter new short supervision time (up to 30 minutes).
Note
Segment 3 is a short supervision window setting (up to
30 minutes) that prevents arming if a transmitter has not
checked in within the set time. This applies only to spe-
cific countries outside the U.S. Check the control panel
installation manual to determine if this setting is available.
Entering a number higher than 30 (the default value is
40) disables the feature.
10. Press [✻] to save any changes. The panel is now wait-
ing for the next location entry.
Note
Pressing [#] does not save changes to the current seg-
ment, but does save changes made in previous seg-
ments.
11. Enter [EXIT] [EXIT] when all changes are completed.
Table 4. Tripping Transmitters for Learning
Transmitter Action
Door/Window, Shock,
Glass Guard, Freeze
Activate tamper switch by
removing cover.
Door/Window with Exter-
nal Contact
Activate tamper switch by
removing cover. (Note:
Feature 4—Input Option
1, must be on.)
Recessed Door/Window Activate tamper switch by
removing circuit board
until tamper switch is
exposed.
Micro Door/Window Slide the battery about
half-way out of the battery
holder, then back.
PIR Activate tamper switch by
removing back plate from
PIR.
Smoke Detector Press and hold the test but-
ton.
Heat Detector Press, then release the
tamper switch.
Fire Pull Activate tamper switch by
removing sensor cover.
Single Button Panic Press and hold the button.
Dual Button Panic Press and hold both but-
tons together.
Keyfobs Press and hold the arm and
disarm buttons together.
Repeater Press, then release the
tamper switch.
