37
REF.
NO.
PART
NO. DESCRIPTION
1 712-0431 Flange Lock Nut, 3/8-16
2 732-0735 Compression Spring, 1.318 x 2.37
3 783-0733 Spacer Cup, 1.5 OD
4 732-0956 Compression Spring, .66 OD x 1.5
5 710-0604A Self Tapping Screw, 5/16-18 x .625
6 710-0751 Hex Cap Screw, 1/4-20 x .62
7 712-0271 Hex Sems Nut, 1/4-20
8 712-3044 Wing Nut, 1/4-20
9 725-1706 12-volt Battery, 270 CCA
10 738-1014 Shoulder Screw, .5 x 1.25, 3/8-16
11 738-1020 Shoulder Screw, .625 x .5, 7/16-20
12 736-0407 Bell Washer, .45 x 1.0 x .062
13 723-0444 Battery Strap
14 783-1031 Hitch Plate
15 725-1747 Safety Interlock Plunger Switch
16 736-0222 Lock Washer, 1/4
17 725-1426 Solenoid, 12-Volt, 100 Amp
18 710-0599 Self Tapping Screw, 1/4-20 x .5
19 712-0459 Flange Lock Nut, 7/16-20
20 683-0304 Lower Frame Assembly
21 756-0639A Engine Pulley, 3.56 OD
22 783-1003 PTO Clutch Bracket
23 712-3010 Hex Nut, 5/16-18
24 710-3180 Hex Cap Screw, 5/16-18 x 1.75 (Grade 5)
25 732-0978 Extension Spring, 1.2 OD x 3.638
26 710-1650 Self-tapping Screw, 5/16-18 x .875
27 710-3025 Hex Cap Screw, 5/16-18 x .625
28 712-3004A Flange Lock Nut, 5/16-18
29 783-0653B Steering Support Bracket
30 683-0293 Idler Bracket Assembly (42-inch Decks)
683-0297 Idler Bracket Assembly (46-inch Decks)
31 738-3056 Shoulder Screw, 1/2 Diameter x 2.5
32 717-1708 Electric PTO Clutch
33 738-0785 Shoulder Spacer, 1.38 x .445 x .36
34 736-0171 Lock Washer, 7/16
35 710-3157 Hex Cap Screw, 7/16-20 x 3.25 (Grade 5)
36 710-3011 Hex Cap Screw, 3/8-16 x 2.25 (Grade 5)
37 756-0627 Flat Idler Pulley, 3.5 OD
38 754-0472 PTO Belt (42-inch Decks)
754-0474 PTO Belt (46-inch Decks)
39 783-0349 Battery Tray
40 783-0891 Deck Stop
41 736-0105 Bell Washer, .401 x .87 x .063
REF.
NO.
PART
NO. DESCRIPTION
Power Take-off System
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Cub Beige,
the part number to order would be 700-
xxxx-0499.
Cub Blue: 0685
Cub Yellow: 0498
Cub Beige: 0499
IMPORTANT: The V-belts found on your tractor are specially designed to engage and disengage safely. A
substitute (non-OEM) V-belt can be dangerous by not disengaging completely. For a proper working machine,
use factory approved belts.
