39
REF.
NO.
PART
NO. DESCRIPTION
1 17982 Reinforcement Spindle Plate
2 618-0430 Spindle Assembly w/ Fitting, 5 Dia.
3 618-0431 Double Pulley Spindle Assembly w/ Fitting
4 683-0254 Deck Adjustment Bracket w/ Weld Nut
5 683-0265B 46-inch Deck Shell
6 710-0167 Carriage Screw, 1/4-20 x .5
7 710-0347 Hex Cap Screw, 3/8-16 x 1.75
8 710-0514 Hex Cap Screw, 3/8-16 x 1.0
9 710-0528 Hex Cap Screw, 5/16-18 x 1.25
10 710-0599 Self Tapping Screw,1/4-20 x .5
11 710-0650 Self Tapping Screw, 5/16-18 x .875
12 710-0751 Hex Cap Screw, 1/4-20 x .62
13 710-1260A Self Tapping Screw, 5/16-18 x .75
14 712-3288 Hex Cap Screw, 1/4-20 x 1.62
15 712-0241 Hex Nut, 3/8-24
16 712-0291 Center Lock Nut, 1/4-20
17 712-0417A Hex Flange Nut, 5/8-18
18 712-0431 Flange Lock Nut, 3/8-16
19 712-3027 Hex Flange Lock Nut, 1/4-20
20 714-0104 Internal Cotter Pin, .072 x 1.12
21 717-1553A Deck Adjustment Gear
22 731-1032B Side Discharge Chute Assembly
23 732-0306 Compression Spring, .406 x .531 x 1.75
24 732-0594A Extension Spring, .91 x 7.33
25 734-0973 Deck Wheel, 5 x 1.38
26 736-0105 Bell Washer, .401 x .87 x .063
27 736-0119 Lock Washer, 5/16
28 738-0347 Shoulder Spacer, .625 x .169
29 738-0373 Shoulder Spacer, .498 x 1.53
30 742-0611 Three-in-one Blade, Star Center, 16.28
31 742-0612 Three-in-one Blade, Star Center, 14.88
32 747-1116 Deck Release Pin
33 754-0349 Deck Belt
34 756-0627 Flat Idler Pulley, 3.5 OD
35 783-0139 Idler Bracket
36 783-0141 Center Deck Skirt
37 783-0142 RH Deck Skirt
38 783-0747 LH Belt Cover
39 783-0805A RH Belt Cover
40 16606 Retainer Hook
41 618-0427 Spindle Assembly w/ Fitting, 5.75 Dia
42 683-0198B 42-inch Deck Shell
43 710-0604A Self Tapping Screw, 5/16-18 x .625
44 712-0181 Top Lock Jam Nut, 3/8-16
45 712-0271 Hex Sems Nut, 1/4-20
46 712-3006 Hex Nut, 1/4-20
47 731-2231 Belt Cover
48 736-0270 Bell Washer, .265 x .75 x .062
49 742-0616 Three-in-one Blade, Star Center, 21.23
50 753-0874 46-inch Deck Assembly Complete
51 731-1643A Mulch Plug, 42-inch Decks
52 712-3087 Wing Nut, 1/4-20
53 712-0291 Center Lock Nut, 1/4-20
54 710-0106 Hex Cap Screw, 1/4-20 x 1.25
55 753-0873 42-inch Deck Assembly Complete
(w/o mulch kit)
56 16606 Retainer Hook
REF.
NO.
PART
NO. DESCRIPTION
Cutting Decks
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Cub Beige,
the part number to order would be 700-
xxxx-0499.
Cub Blue: 0685
Cub Yellow: 0498
Cub Beige: 0499
