41
REF.
NO.
PART
NO. DESCRIPTION
1 710-0148 Self-tapping Screw, #8-32 x .375
2 710-0599 Self-tapping Screw, 1/4-20 x .5
3 710-0604A Self-tapping Screw, 5/16-18 x .625
4 710-1237 Screw, #10-32 x .625
5 710-1314 Socket Cap Screw, 5/16-18 x .625
6 710-1315 Self-tapping Screw, 3/8-16 x 1.25
7 712-3017 Hex Nut, 3/8-16
8 721-0460 Exhaust Gasket (Intek Twin)
9 726-0205 Hose Clamp
10 736-0119 Lock Washer, 5/16
11 736-0300 Flat Washer, .406 x ..875 x .059
12 751B221535 Casing Clamp
13 751-0535 Fuel Line Hose
14 751-0564 Muffler Deflector
15 751-0616 Muffler, Twin Inlet
16 751-0650 RH Exhaust Pipe (Intek Twin)
17 751-0651 LH Exhaust Pipe (Intek Twin)
18 751-3140 Oil Drain Valve
19 751-3141 Oil Drain Hose
20 751-3142 Oil Drain Cap
21 783-0615 Muffler Heat Shield
22 783-0625B Engine Heat Shield
23 722-0263 Foam (fits over fuel line)
24 746-1086 Throttle Cable (Intek Twin)
25 746-1084 Throttle/Choke Cable (Intek Single)
26 751-0619 Exhaust Pipe (Intek Single)
27 751B213146 Casing Clamp
28 751-0617 Muffler, Single Inlet
29 712-0271 Hex Sems Nut, 1/4-20 (for starter cable)
30 721-0208 Exhaust Gasket (Intek Single)
31 732-0966 Extension Spring, .275 x 1.25
Engine Accessories
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Cub Beige,
the part number to order would be 700-
xxxx-0499.
Cub Blue: 0685
Cub Yellow: 0498
Cub Beige: 0499
