Cadex TRI - Saddle Clamp Adjustment

|ENGLISH| CADEX TRI USER MANUAL
14
SADDLE CLAMP ADJUSTMENT
1. Remove saddle (A).
2. Loosen and remove both clamp fixing bolts (B).
3. Pull out clamp , turn it 180° horizontally and refit it into seat post (C).
4. Replace clamp fixing bolts , tighten to 5Nm (D).
SEAT POST
Minimum insertion - 80mm.
A
B
C
D
