Cadex TRI - Saddle Position Adjustment

|ENGLISH| CADEX TRI USER MANUAL
15
NOTE:
1. Always use a torque wrench
2. Once the installation or adjustment has been completed, grab the saddle and rock it back and forth to ensure all
fasteners are snug.
SADDLE POSITION ADJUSTMENT
1. Loosen the side bolt a full turn; Loosen the top bolt a full turn (A)
2. Adjust saddle angle, fore or aft to preferred position (B).
3. Tighten the top bolt to 5 Nm with 4 mm hex; Tighten the side bolt to 5 Nm with 4 mm hex (C)
4. Double check clamp fixing bolts ➌ (D)
A
B
C
D
➌
