|ENGLISH| CADEX TRI USER MANUAL
16
SADDLE REMOVAL & INSTALLATION
1. Loosen and remove the side bolt (A).
2. Loosen and remove the top bolt and the upper piece (B).
3. Remove the saddle from the clamp. Rock the saddle back and forth to help removal. (C).
4. Select 7mm top clamp for alloy rail saddle or 9mm top clamp for carbon rail saddle. ➍ (D)
5. Apply carbon paste to the clamp housing (E).
6. Replace top clamp ➍ and loosely tighten the top bolt and upper piece (F).
A
B
D
E
F
C
➍
➍
