ESCALADE/ESCALADE ESV
INSTRUMENT CLUSTER
1. Security Light
2. Malfunction Indicator Lamp (MIL)/Service Engine
Soon Light
3. Turn Signal Indicator
4. Cruise Control Light
5. Air Bag Readiness Light
6. Safety Belt Reminder Light
7. Headlamp High Beam Indicator Light
8. Transmission Temperature Gauge
9. Tachometer
10. Antilock Brake System Warning Light
11. Brake System Warning Light
12. Speedometer/Gear Selector Indicator
13. Driver Information Center (DIC) Display
14. Tow/Haul Mode Light
15. Traction Off Light
16. Charging System Light
17. Oil Pressure Gauge
18. Fuel Gauge
19. Voltmeter
20. Engine Coolant Temperature Gauge
Important: The instrument cluster
is designed to let you know about
many important aspects of your
vehicle’s operation. The message
center can provide critical information
to prevent damage to your vehicle.
It is important to read your Owner
Manual and become familiar with the
information that is being relayed to
you by the lights, gauges and
indicators, particularly the message
center, and what action can be taken
to ensure your safety and to prevent
damage.
21 12
3
14
15
19
20
3
16
8
4
10 11
9
5
6
7
13 1817
