Circuit
Breakers
Usage
CB1
Front Passenger’s Seat, Memory
Seat Module
CB2
Driver’s Power Seat, Memory
Seat Module
CB3 Door Module, Power Windows
CB4
Memory Seat Module, Tilt/
Telescoping Steering Wheel (Option)
Resistor Usage
F39 Terminating Resistor
Relays Usage
R1 Retained Accessory Power
R2 Park Lamps
Relays Usage
R3 Run (Option)
R4 Park Lamps (Option)
R5
Front Heating, Ventilation, Air
Conditioning Fan
R6 Trunk Release
R7 Fuel Pump
R8
Door Unlatch, License Plate
Lamp (Option)
R9 Door Lock
R10 Door Unlock
R11 Overhead Lamps (Option)
R12 Stoplamps (Option)
R13 Not Used
R14 Rear Defogger (Option)
R15
Electronic Leveling
Control Compressor
5-100
