CARE AND CLEANING
Replacing LED Lamp
Cooktop Light/Nite Light
Replace with LED lamp. See back cover for ordering
online at cafeappliances.com.
1
To replace the cooktop light/nite light, first disconnect
the power at the main fuse or circuit breaker panel,
or pull the plug.
2
Remove the screw from the side of the light
compartment cover and lower the cover until it stops.
3
Be sure the LED lamp is cool before removing.
Remove a screw and connector from LED lamp.
4
Connect LED lamp and secure using the screw.
Raise the light cover and replace the screw. Connect
electrical power to the oven.
Remove screw.
