3.0 VALUE / LIMIT CHECKING
The purpose of this section of the document is to lay down the allowable range of adjustment for all
functions addressable over the communications link.
LEVEL C
Function Values / Limits
ADR 1 — 247
BAUD 1200 2400 4800 9600 19200
DATA 18N1 18E1 18O1
DBUG OFF ON
LEVEL 1
Function Values / Limits
TUNE OFF ON PARK AT.SP
BAND 0.1 — 9.9 10 — 25% of the selected sensors full scale, deg C or F
(9500 - 100% of the selected sensors full scale, deg C or F)
INT.T OFF 0.1 — 9.9 10 — 60 Minutes
DER.T OFF 1 — 200 Seconds
DAC 0.5 — 5.0 ( In 0.5 steps)
CYC.T A-- ON.OF 0.1 — 9.9 10 — 81 Seconds
OFST Detailed later dependant on other functions.
SP.LK OFF ON
SPRR 0 — 9990 Deg / Hr
SPRN ON OFF HOLD
SOAK -- 0 — 1440 Min
SET.2 Detailed later dependant on other functions.
BND.2 Detailed later dependant on other functions.
CYC.2 ON.OF 0.1 — 9.9 10 — 81 Seconds.
LEVEL 2
Function Values / Limits
SP1.P 0 - 100 % ( Read only )
HAND OFF 1 — 100 %
PL1 100 — 0 %
PL2 100 — 0 %
SP2.A NONE DV.HI DV.LO BAND FS.HI FS.LO COOL E.OP (9500P)
SP2.B NONE LT.CH HOLD LT.HO NLIN
DISP 1 Deg 0.1 Deg
HI.SC Detailed later dependant on other functions.
LO.SC Detailed later dependant on other functions.
INPT NONE B E J K L N R S T RTD LIN1 LIN2 LIN3 LIN4 LIN5
(9500 — LIN1-5 replaced by LIN )
UNIT NONE *C *F BAR PSI PH RH SET
LEVEL 3
Function Values / Limits
SP1.D NONE RLY SSD RLY1 RLY2 SSD1
(9500 — NONE RLY SSD ANLG depending on hardware present)
SP2.D NONE RLY SSD RLY1 RLY2 SSD2 (9500 as above)
BURN UP.SC DN.SC 1U.2D 1D.2U
REV.D 1R.2D 1D.2D 1R.2R 1D.2R
REV.L 1N.2N 1I.2N 1N.2I 1I.2I
SPAN Detailed later dependant on other functions.
ZERO Detailed later dependant on other functions.
READ VAR* HI* LO* ( Read only ).
TECH CTA CTB CT1 CT2 CT3 CT4 OS1 US OS2 (Read only ).
VER 391 392 941 951 952 ( Read only ).
RSET NONE ALL
