TABLE 1 MIN/MAX SENSOR FULL SCALE DEGREE C
SENSOR MIN MAX MIN 0.1 MAX 0.1
B 0 1800 0.0 999.9
E 0 600 0.0 600.0
J 0 800 0.0 800.0
K - 50 1200 - 50.0 999.9
L 0 800 0.0 800.0
N - 50 1200 - 50.0 999.9
R 0 1600 0.0 999.9
S 0 1600 0.0 999.9
T - 200 250 - 199.9 250.0
RTD - 200 400 - 199.9 400.0
LIN1 0 400 0.0 400.0
LIN2 - 25 400 - 25.0 400.0
LIN3 0 3000 0.0 999.9
LIN4 - 250 3000 - 199.9 999.9
LIN5 0 3000 0.0 999.9
LIN
(
9500
)
0 9999 N/A N/A
TABLE 2 MIN/MAX SENSOR FULL SCALE DEGREE F
SENSOR MIN MAX MIN 0.1 MAX 0.1
B 32 3272 32.0 999.9
E 32 1112 32.0 999.9
J 32 1472 32.0 999.9
K - 58 2192 - 58.0 999.9
L 32 1472 32.0 999.9
N - 58 2192 - 58.0 999.9
R 32 2912 32.0 999.9
S 32 2912 32.0 999.9
T - 273 482 - 199.9 482.0
RTD - 273 752 - 199.9 752.0
LIN1 N/A
LIN2 N/A
LIN3 N/A
LIN4 N/A
LIN5 N/A
LIN
(
9500
)
N/A
