CalAmp TTU-2830 User Manual

50 channel WAAS capable GPS Receiver
2.5m CEP (with SA off)
-162 dBm tracking sensitivity
Communications (Comm)
Data Support
SMS, GPRS, CDMA 1xRTT or HSPA packet data
GSM/GPRS Quad-Band
850/900/1800/1900 MHz
GSM/GPRS Output Power
Class 4 (2 Watts) 850/900 bands
Class 1 (1 Watt) 1800/1900 bands
CDMA Dual-Band
800/1900 MHz
CDMA Output Power
800: +24dBm
1900: +24dBm
HSPA/UMTS Dual-Band
900/2100 MHz (bands VIII, I) or
850/1900 MHz (bands V, II)
3GPP release 6
5.6 Mbps upload, 7.2 Mbps download
GSM/GPRS Fallback
850/900/1800/1900 quad-band
GPRS class 12, EDGE MCS1-MCS9
RoHS Compliant
3.2 Primary Connector
The TTU-2830™uses 8 22AWG leads for its power and I/O connections. These leads are
mapped as follows:
Wire
Signal
Name
Description Color
Input or
Output
1 GND Ground Black Ground
2 V
CC
Primary Power Red Input
3 IN-0 Input 0 – Ignition White Input
4 IN-1 Input 1 – Digital Input Blue Input
5 IN-2 Input 2 – Digital Input Orange Input
6 OUT-0
Ouput 0 – Starter Disable
Relay Driver
Green Ouput
7 OUT-1 Ouput 1 – Digital Output Brown Ouput
8 OUT-2 Ouput 2 – Digital Output Yellow Ouput
