Page 33
NOTE: WATKINS WELLNESS recommends that the CANTABRIA be installed on a minimum 10 cm thick reinforced concrete pad or structurally sound deck able to support
the “dead weight” found in the spa specification chart.
WARNING: The CANTABRIA must not be shimmed in any manner.
CANTABRIA
Dimensions
NOTE: All dimensions are approximate; measure your spa before making
critical design or pathway decisions.
108.0” (274 cm)
32.5”
(83 cm)
38”
(97 cm)
102.0” (259 cm)
85.125”
(216 cm)
93.375” (237 cm)
13”
(33 cm)
61.5” (156 cm)
91”
(231 cm)
Cabinet
(Front View)
Door Opening
Front Panel
Drain
(Center of Spa)
Electrical Cut-Out
(both sides)
4" (10 cm) up from
bottom of spa
(Bottom View)
Air Vent
Do Not Block
Air Vent
Do Not Block
Air Vent
Do Not Block
Base Pan
Side Walls
Base Pan Side Walls
DOOR SIDE
Electrical Cut-Out
(both sides)
Installation Instructions
