Caledonian Audio 6BM8/ECL82 SE - Page 20

!
20!
!
H9Q,<#(WX(@(?P#(N=$O &#?#("'" ?#$ !
(
(
(
(
5N<#S0B,?"0.=&?"(59_#"(
!
All!fixings!are!included!in!the!kit.!Table!below!summarizes!the!sizes!of!the!fixings!
used!for!all!parts.!
!
Y*<?( (
H9R9+Q"(
Output!transformer!
• Slot! Pan! Head! Machine! Screw!
Brass!Nickel!Plated,!M4,!20mm!
• RS! PRO,! M4,! Bright! Zinc! Plated!
Steel!Nylon!Insert!Lock!Nut!
• Bright! Zinc! Plated! Steel! Plain!
Washer,!0.8mm!Thickness,!M4!
Main!transformer!
• Included! in! the! transformer!
package!
Please! make! sure! that! the! core! of! the!
transformer! sits! flushed! on! the!
mounting! plate! (i.e.! no! washer! in!
between! the! mounting! plate! and! the!
body!of!the!transformer)!
PCBs!(all)!
• Slot! Pan! Head! Machine! Screw!
Brass!Nickel!Plated,!M3,!6mm!
• RS! PRO! Steel! Hex! Standoff!
Female/Female,! 20mm,! M3! x!
