Speaker*Output*Wiring*
!
The! aim! for! this! section! is! to! connect! the! secondary! winding! of! the! output!
transformer!to!the!speaker!terminals.!!
!
There!are!4!speaker!terminals!in!the!system.!Each!channel!contains!the!positive!
(hot)!and!negative!(ground)!cables.!!
!
We!will!start!with!one!channel!first.!
./"0-1(?"--'2%$"-(
Connect!the!“0”!terminal!on!the!Secondary!winding!of!the!output!transformer!to!
the!ground!(negat ive)!speaker!terminal.!This!is!the!single!core!insulated!copper!
wire!seen!in!Figure!31!-!connecting!the!output!transformer!to!speak er!term in als.!Then,!
connect!the!same!speaker!terminal!to!the!star!ground.!!
!
