BS...IMAT Rev2 9 / 12
ELECTRICAL DIAGRAM
EASYMAT1-3= Frequency converter
EASYMAT 1
1 2 3
Supply
50/60Hz
8 9
10 11
8 9
10 11
8 9
10 11
8 9
10 11
EASYMAT 2 EASYMAT 3
Panel Type
QTE3 -10M
QTE3 -16M
QTE3 -20M
MCB (1,2,3)
10A
16A
20A
MCB2 MCB3MCB1
ISL
