8 / 12 BS...IMAT Rev2
10 ELECTRICAL DIAGRAM
EASYMAT1-2= Frequency converter
EASYMAT 1
Supply
50/60Hz
8 9
10 11
8 9
10 11
8 9
10 11
EAS
MCB2
ISL
MCB1
YMAT 2
2
Panel Type
QTE2 -10M
QTE2 -16M
QTE2 -20M
MCB (1,2)
10A
16A
20A
