CAMDEN CX-12 User Manual

FILENAME: CX_12 Diagram 3a.vsd
DRAWING No: DRG-CX12-03a
CX-12 Application Diagram for Apartment (typical)
SCALE: NONE DRAWN BY: DGW REVISED: DATE: 11/16/09
Camden Manufacturing
5502 Timberlea Blvd.
Mississauga, Ontario
L4W 2T7
12 - 24 V
AC/DC
Power
Optional
Vestibule mounted
Convenience Switch
(Only active when
Lock relay energized)
Switch opens door
Electric Strike
Door Operator
MOV
Wire MOV
(supplied)
directly to strike
or magnet
Power
for Strike
Apartment
Interphone
Panel
(powered signal)
Unlocks door only
Interior Switch
Unlocks and
opens door
1 52 3 4 6 7 8 9 10 11 12 13 14 15 16
RL1
LED
RL2
LED
DOR
RL1
DOO
RL2
DOR
RL2
Off / On
1
2
CX-12
